OFHB26 - 26 Inch High Brightness Display
| OFHB26 SPECIFICATIONS |
| Panel Display |
| Display Size |
26.0 inches |
| Resolution |
1600 x 900 WVGA |
| Nits |
1000 |
| Contrast Ratio |
3000 |
Viewing Angle
(up/down),(right/left) |
89/89 , 89/89deg |
| Operating Temperature |
0 to +50deg C |
| Backlight |
CCFL |
| Panel Mode |
Transmissive |
| Interface |
LVDS |
| Lead Free / Rohs |
|
| |
| Display Area |
575.769 (H) x 323.712(V) mm |
| Outline Dimension |
626.0 (H) x 373.0 (V) x 45.0(D) mm |
| Display Colors |
16.7M Colors |
| Number of Pixels |
1600 x 900 Pixel |
| Pixel Pitch |
0.4215 mm |
| Pixel Arrangement |
RGB vertical stripe |
| Display Mode |
Normally Black |
| Panel Type |
a-Si TFT-LCD |
| Surface Treatment |
AG, Haze=11%, 3H |
| |
| Video Inputs |
DVI-D, VGA |
| Power Input |
110 volts A/C |
Order Information
MON-OFHB26 - 26 inch High Brightness Monitor Open Frame
|
|
|
|
|
