OFHB42 - 42 Inch High Brightness Display
| OFHB42 SPECIFICATIONS |
| Panel Display |
| Display Size |
42.0 inches |
| Resolution |
HD Resolution 1920 x 1080 Full HD |
| Nits |
1000 |
| Brightness |
300 cd/m2 (Typ.) |
Viewing Angle
(up/down),(right/left) |
89/89 , 89/89deg |
| Operating Temperature |
0 to +50deg C |
| Backlight |
WLED, 120Hz |
| Panel Mode |
Transmissive, AMVA3, Normally Black |
| Interface |
LVDS |
| Lead Free / Rohs |
|
| |
| Display Area |
930.24×523.26 mm (W×H) |
| Outline Dimension |
|
| Display Colors |
16.7M Colors (8-bit) |
| Number of Pixels |
1920 x 1080 Pixel |
| Pixel Pitch |
0.4215 mm |
| Pixel Arrangement |
RGB vertical stripe |
| Display Mode |
Normally Black |
| Panel Type |
a-Si TFT-LCD |
| Surface Treatment |
AG, Haze=11%, 3H |
| |
| Video Inputs |
DVI-D, VGA |
| Power Input |
110 volts A/C |
| Weight |
8.0Kgs |
Order Information
MON-OFHB42 - 42 inch High Brightness Monitor Open Frame
|
|
|
|
|
